Fleurco – LATITUDE Pivot 2-Sided
Fleurco - LATITUDE Pivot 2-Sided
Product Details
5/16″ tempered glass, shower height 2-Sided pivot door. 1 pivoting panel and 2 fixed panels. In & out pivoting system with 90º inward and 90º outward opening. Reversible left or right door installation on wall, fixed panel or return panel. Shatter Retention Technology (S.R.T) glass for added protection. Silk screen design – won’t peel over time. Sleek vertical handle. Magnetic closure. Microtek glass surface protection included.
| Enclosure Name | LATITUDE Pivot 2 Sided |
|---|---|
| Collection | LATITUDE |
| Enclosure Operation | Dual-Acting Pivot (in and out) |
| Unit Height | 79″ (79-3/4 to top of support bar) |
| Unit Width | Various options – See below |
| Glass | 5/16″ Clear |
| Finishes | Matte Black |
| MICROTEK Glass Protection | Included |
| Customizable Dimensions | NO |
| Width Dimensions | ||
|---|---|---|
| FRONT | Model | Distance from side wall to center of wall jamb |
| LAP248 | 45-1/2″ to 46-1/8″ | |
| LAP254 | 51-1/2″ to 52-1/8″ | |
| LAP260 | 57-1/2″ to 58-1/8″ | |
| RETURN SIDE | Return Panel Options | Finished wall to center of wall jamb |
| 32″ Base | 29-1/4″ to 29-3/4″ | |
| 36″ Base | 33-1/4″ to 33-3/4″ | |
| 42″ Base | 39-1/4″ to 39-3/4″ | |
| 48″ Base | 45-1/4″ to 45-3/4″ | |
Enclosure Shape:
2 Sided Shower
